Experience the ultimate audio upgrade with the American Bass AB-5B-ECV Equalizer, a high-performance 5-Band Parametric Pre-amplifier designed to elevate your car audio experience. This versatile equalizer allows you to fine-tune your sound by balancing frequencies, reducing distortion, and enhancing audio clarity, providing a richer and more immersive listening experience. Key features include adjustable input sensitivity, master volume control with up to 8 volts of RMS output, and a stylish night illumination design. Whether you're a casual listener or an audiophile, the AB-5B-ECV Equalizer will help you tailor your car audio system to your preferences, ensuring a consistently enjoyable experience on the road.
| POWER SUPPLY | 11-15 DC NEG. GROUND |
| MAX. OUTPUT VOLTAGE | 8V |
| PRE GRAPHIC FREQUENCY | 50Hz, 120Hz, 900Hz, 2.2KHz, 16KHz |
| EQUALIZATION RANGE | +12dB |
| SUBWOOFER FREQUENCY | 10Hz-300Hz |
| INPUT IMPEDANCE | 10K OHMS |
| S/N RATIO | 90 dB |
| THD | 0.05% |
| CHANNEL SEPARATION | 82dB/1kHz |
| FREQENCY RESPONSE | 10Hz-50KHz(-3dB) |
