Introducing the American Bass DB Series Amplifier, one of the latest additions to our lineup, designed with affordability and competitiveness in mind. This versatile amplifier series features both two-channel and four-channel high-frequency amps, perfect for those seeking a powerful audio system without breaking the bank. Engineered to deliver loud and clear audio at a fraction of the cost of other amplifiers, the DB Series is a fantastic investment for audiophiles on a budget. The American Bass DB Series Amplifier is your go-to choice for cost-effective, high-quality audio performance.
|
RMS @ 1OHM |
NA |
|
RMS @ 2OHM |
2X130W |
|
RMS @ 4OHM |
2X75W |
|
BRIDGE @ 4OHM |
1X220W |
|
LOW PASS FILTER |
40-180HZ |
|
HIGH PASS FILTER |
NA |
|
BASS BOOST |
0-12dB |
|
BASS BOOST FREQUENCY |
30-80Hz |
|
SUBSONIC FILTER |
10-50Hz |
|
FREQUENCY RESPONSE |
20-190Hz |
|
S/N |
90DB |
|
INPUT SENSITIVITY |
0.2-6V |
|
THD |
<1% |
|
OPERATION VOLTAGE |
9-16V |
|
FUSE RATINGS |
25A |
|
DIMENSION |
7.08X9.45X1.97 INCHES |
